Home > Products > Foil Containers > Standard Smoothwall

Standard Smoothwall

Smoothwall trays have a smooth rim, which allows each tray to be hermetically heat sealed with standard film on high speed machines. Gas flushing techniques can be incorporated into the filling and sealing phases of meal production. Their robust construction enables sleeves and cartons to be lightweighted, reducing total pack costs.
Product Code Description Top Out(mm) Top In(mm) Base(mm) Depth(mm) Capacity(cc) Case Size
  4031 WW-042-500 234X138 218X122 203X107 50 1,100 420
  4034A WN-037-300 600
  4048 WW-037-501 265X165 247X147 234X134 75 2,300 200
  4100 CS-440610-200 178X136 164X122 155X113 34 610 540
  4102 CS-441600-500 220X150 202X132 184X114 70 1,600 400
  4103A CS-441061-502 218X126 202X110 187X95 60 1,061 240
  4104A CS-441063-503 218X127 202X111 187X96 60 1,063 240
  4105A CS-440800-500 220X150 202X132 192X122 34 800 500
  4105LW CS-440800-505-LW 500
  4105MR CS-440800-506 220X150 202X132 192X122 34 800 500
  4106A CS-440656-500 198X108 182X92 166X76 50 656 480
  4107 CS-441000-500 220X150 202X132 175X119 45 1,060 470
  4107R CS-441000-501 R 220X150 202X132 175X119 45 1,060 470
  4108 CS-441059-500 220X150 202X132 189X119 45 1,060 450
  4108MR CS-441059-506 220X150 202X132 189X119 45 1,060 450
  4109A CS-440790-501 178X136 164X122 151X109 45 790 520
  4110 CS-441190-502 218X128 202X110 182X90 70 1,190 345
  4111 CS-441135-500 265X162 247X134 237X134 37 1,187 360
  4112A CS-441450-500 265X162 247X144 234X131 47 1,450 320
  4115 EC-442000-200 293X193 279X179 266X166 45 2,000 600
  4116 CS-440582-500 150x125 132x107 119x94 50 582 620
  4117 CS-440725-500 234X128 218X122 210X114 30 725 500
  4118 WW-032-501 220X130 202X112 118X98 58 1,080 360
  4119 WW-033-501 220X130 202X112 190X100 70 1,200 250
  4162 WW-040-500 236X185 218X167 201X150 49 1,480 230
  4164 WW-043-500 293X193 275X175 260X160 85 3,560 225
  4165 CS-440980-500 188X147 172X131 157X116 50 980 500
  4166 CS-441165-502 237X182 220X165 210X35 35 1,165 180
